DINA-DR1-LITE DIN Rail Lighting Controller

Description

Entirely based on the DINA-DR1 lighting controller the LITE version comes with limited but expandable features. Because there is no perfect controller for all projects the DR1 LITE is the “on demand” answer to the most demanding projects. Designed for din-rail mounting the DR1 LITE is a strong and durable solution for fixed lighting installations. 1024 (expandable to 6144 with eDMX) channels (341 RGB or 256 RGBW fixtures) can be controlled over several protocols : DMX 512 Art-Net or SACN LED Pixel* DALI*. Multiple controllers can be connected and synchronised for large-scale lighting installation.Built on the NSA (New Stand Alone) engine the DR1 LITE offers multi-zone show control as well as advanced and flexible triggering and integration possibilities: Time Audio* Ports RS232* TCP DALI*…This is the first lighting controller offering an all-in-one solution with multiple protocols. The DR1 LITE can output DMX Art-Net SACN DALI* LED pixel* and create a control gateway for the most demanding dynamic lighting installations.There is nothing easier than programming the DINA-DR1 LItE: connect the controller to your computer (PC or Mac) over USB/Ethernet and start the ESA2 or ESA Pro 2 software.*Optional features via license upgrade
