Jolt Panel FXIP

Name: Jolt Panel FXIP - Power-Hub
Brand: ADJ
SKU: ADJ1226200074
Price: 720.59 GBP
Availability: InStock

Free Delivery on this item!

£720.59

ex. VAT inc. VAT

In stock

An innovative multi-use strobe / wash / eye candy fixture. It is equipped with 800 x 0.5-Watt RGB SMD LEDs for colour strobe wash and eye candy effects as well as 48 x 5-Watt white SMD LEDs located.

In stock

Open a Trade Account

Business customers can apply in minutes. No fees, fast approval, exclusive trade pricing and volume discounts.

Create Account

We accept

Add to wishlist

Delivery 2-4 working days (Mon-Sat delivery between 08:00 and 17:00)

Premium Courier Service: Trackable delivery to your business premises

14-day hassle-free return policy — no questions asked

24/7 Customer Support: Help is always available, day or night

SKU: ADJ1226200074

Categories: Lighting, Strobes

Brand: ADJ

Description

The ADJ Lighting Jolt Panel FXIP is an innovative multi-use strobe / wash / eye candy fixture. It is equipped with 800 x 0.5-Watt RGB SMD LEDs for colour strobe wash and eye candy effects as well as 48 x 5-Watt white SMD LEDs located in the centre of the fixture to create the traditional look of a strobe. Both types of LED are grouped into independent controllable zones (6 white and 40 colour) allowing for the creation of eye-catching animated chase patterns. The Jolt Panel FXIP’s massive light output is specifically designed for large stages nightclubs live events and touring.

Building off the success of the original Jolt Panel FX the new Jolt Panel FXIP features upgrades that will help Lighting Designers add a new level of creativity to their lightshows. The fixture is IP65-rated for temporary outdoor or indoor use. ADJ’s proprietary Aria X2 wireless DMX is built-in to each fixture (it is also compatible with ADJ’s WiFLY EXR wireless DMX) which allows data distribution to occur wirelessly. There is a channel system on the front of the unit that allows for light shaping filters to be easily and conveniently added to the fixture. These filters blur the pixel dots and provide designers with another creative way to change the effect from project to project.

The Jolt Panel FXIP offers users an easy way to navigate the built-in features from an LCD display with a 4-button menu system. The display allows users to change dimming modes dimming speed programs colour macros LED refresh rate and gamma settings as well as setting the DMX address and channel modes. The rear panel has conveniently located IP65-rated 5-pin DMX in/out connections along with IP65 locking power in/out sockets to daisy chain power. There are also holes to connect an omega bracket to the Jolt Panel FXIP as an alternative to its variable angle bracket.

Manufacturer Part Number: 1226200074 Dimensions (L x W x H): 42.0 x 15.0 x 26.0cm

LIGHT SOURCE:

800 x 0.5-Watt RGB SMD LEDs + 48 x 5-Watt Cool White SMD LEDs Beam Angle: 73° Field Angle: 111° RGB LED Specs: Red: 620-630nm; Green: 515-530nm; Blue: 460-470nm White LEDs CCT: Typical 7400K (Min. 6900 - Max 8000) 472nm CRI: 69.4 50000 Hour Average LED Life

FEATURES:

Aria X2 Wireless Management System 40 x RGB LED Zones (126 141 and 143 ch modes) 6 x Cool White LED Zones (51 81 83 126 141 and 143 ch modes) 67 Built-In Colour Temperature Presets (2300K-8900K) 25 Built-in RGB LED Program Macros 9 Built-in Cool White LED Program Macros IP65-Rated for temporary outdoor and indoor use Channel for Light Shaping Filters (to Blur Pixel Dots) Built-in Holes to Connect an Omega Bracket (sold separately)

CONTROL:

Control Protocols: DMX Aria X2 and RDM 10 DMX Channel Modes: 6 9 13 18 36 41 51 81 126 and 141 channel modes Dim Modes: 6 Presets (Standard Stage TV Architectural Theatre & Stage 2) Dim Curves: 4 Presets (Linear Square Law Inv Square Law & S Curve) 0-100% Smooth Dimming Strobe Shutter & Pulse Control Max Strobe Rate: 20Hz; Min Strobe Rate: 1Hz Refresh Rate: 900Hz - 25kHz Display: OLED Display with 4-Button Touch Menu

CONNECTIONS:

Data: IP65-rated Locking 5-pin DMX In/Out Power: IP65 Locking Power In/Out

ELECTRICAL:

Multi-voltage operation: AC100-240V 50/60Hz (Auto Sensing) Max Power Consumption: 208W @230V Max Power Link: 12pcs @230V Fuse Protected: T5A/250V Glass Fuse (5x20MM)

DIMENSIONS / WEIGHT:

Length: 417mm Width: 280mm Height: 213mm Weight: 9.1 kg

WHAT'S INCLUDED:

1x IP65 locking power cable Diffusion filter

OPTIONAL ACCESSORIES:

180mm Omega Bracket Hydro (SKU 9900026435) Jolt Panel FX BLKF Jolt Panel FX 1x60 LF (60x1° Beam Shape filter) Jolt Panel FX 60x1 LF (1x60° Beam Shape filter)

APPROVALS / RATINGS:

IP65
